Flexline-R Rapid-Clamping System, sturdy version
Hollow-piston cylinder: 245 bar / 100 kN or 400 bar / 104 kN
The electro-mechanical driven push chain moves the clamping element attached to the Flexline-R rapid-clamping system automatically from the
parking position to the clamping position at the clamping edge and then back to the parking position.
The T-slot of the machine serves as the guide for the push chain and clamping element. The push chain also serves as the energy chain for accommodating the hydraulic and electric lines of the clamping element.
Application
Rapid clamping systems are used for the automatic clamping of dies of varying sizes on the press ram.
Advantages
- Extremely robust, welded pull-push chain made of stainless steel
- Chain case, bracket and sheet metal parts made of reinforced material and stainless steel
- Drive motor with manual emergency stop
- Chain case with slot for additional position monitoring (end of chain or intermediate position)
- Harting connector code class IP65 (no open junction box)
- Compact drive unit and lightweight
- Four different clamping elements and two adjustment tracks freely selectable
- Easy to service, easily exchangeable assemblies
- Highly flexible, low-maintenance hydraulic hoses with high burst pressure
- Drive motor selectable on left or right side
Versions
Flexline-R rapid-clamping system can be supplied in the following variants:
- Clamping element: Hollow-piston cylinder, single or double acting
- T-slots: 28 or 36 mm or 1 1/16"
- Adjustment tracks (clamping element displacement path) 660 or 1100 mm
- Electrical drive motor
- Different Harting connectors for motor current and query signals selectable
- Option: position monitoring "end of chain", adjustable
- Option: design with UL-compliant components
- Option: socket housing for mounting on the machine
- Option: drive motor or position monitoring of the "die position" attached on the left or right side
Rapid clamping system with pusher chain fixed to the press ram of a double-column press. A hollow-piston cylinder serves as clamping element.
Rapid clamping system at multi-stage press
Clamping force 100 kN/ clamping position, travelling path 1000 mm
Rapid clamping system with pusher chain in a press line.
12 clamping positions are clamped or unclamped within 5 seconds at the push of a button
Detail view: Rapid clamping system with pusher chain at the press ram. Mounted clamping element: Clamping cylinders with locking and automatic self-locking
